Amigo RD 3-Wheel Scooter w/33AH Batteries

• 350 lb. weight capacity
• Value Priced & Deluxe Model Available
• Sealed, lifetime-lubricated, drive system
• Small turning radius and rear wheel design

The Amigo® RD 3-Wheel Scooter is one of our most popular models. Offered in either a Value or Deluxe package, personal features tailored to your needs promote freedom, mobility and an active lifestyle. The combination of a small turning radius and rear wheel drive design allows you to maneuver through your kitchen or bathroom and travel around your backyard or garden. With a 350 lb. weight capacity (250 lb. with Power Seat Lift), infinitely adjustable handle, 360° seat rotation, and optional power seat lift, the Amigo RD comfortably accommodates most users. Do more, see more, experience more. Let the Amigo RD offer you a world of activity! The Amigo® RD is available in Cinnamon Red, Scuba Blue, Emerald Green & Champagne Beige.

	Value Model	Deluxe Model
Price	$2,365	$2,785
Handle	Standard Hi/Lo	Touchtron Horn Brake Release Speed Indicator Battery Meter
Seat Post	Std pin adjustable	Power Seat Lift 4-3/4” Vertical Travel Seat to Platform at low: 16” Max user Weight: 250#
Charger	Onboard 24 v	Onboard 24 v
Seat	Premier I Plastic, Folding, w/ Black Upholstery	Premier I Plastic, Folding, w/ Black Upholstery
360° Swivel Seat Lock	Standard Right	Standard Right
Front Wheel	Steel w/9” Flat Free Tire	Steel w/9” Flat Free Tire
Rear Wheels	Aluminum Mag w/10.5” Trimline Pneumatic Tire	Aluminum Mag w/10.5” Trimline Pneumatic Tire
Lights	Running Light	High Intensity Light Pkg Hi-Intensity Light Tail Lights Turn Signals
Front Basket	Included	Included
Batteries (2)	U-1 33AH Gel Included	U-1 33AH Gel Included
Suggested Retail	$2,794	$3,579

Other Standard Features:

• Great for someone on a tight budget.
• Sleek, stylish design.
• Does NOT disassemble for transport.
• Excellent for indoor and outdoor use.
• Seat offers height adjustment, 360 degree rotation and flip-up arms.
• Adjustable tiller for maximum comfort.
• Headlight for added safety.
• On-Board 24 V Battery Charger w/ Retractable AC Cord.
• Easy-to-use external freewheel lever.
• Weight capacity of 350 lbs. (250 lbs. w/ Power seat)
• Up to 35 miles per charge.
• Maximum speed 5.9 mph.
• Flat-free Front tire
• Pneumatic Rear tires
• Lifetime limited warranty

Amigo® RD Model 310000 Standard Specifications:

• Steel, painted, one-piece platform Scooter DOES NOT disassemble
• Overall Length: 43.8"
• Overall Width: 22.8"
• Per-charge Range (Max): up to 35 Miles. (varies w/ passenger weight, terrain type, battery charge and condition)
• Maximum Speed: up to 5.9 MPH variable
• Turning Radius: 34"
• Total weight, including batteries: 162 lbs.
• Weight w/o Batteries: 110 lbs.
• Wheels: Front – Steel, Rear - Aluminum mags
• Tires: Front - 3" x 9" Solid, Rear - 4" x 10.5" Pneumatic
• Ground Clearance: 3.5"
• Black rear safety bumper with stability wheels
• Battery: (2) 32 AH, 12V deep cycle (AGM or gel cell)U-1
• Battery (optional sizes): N/A
• Battery Weight: 26 lbs. Each
• Battery Charger: 3-Amp (On-board) Has Retractable AC Cord
• Drive System: Rear-wheel drive, Unipac® & Vari-Speed, Sealed, lifetime-lubricated, No belts or chains, 24 volt DC motor
• ASIC MPC electronics controller
• Dual Braking System: Dynamic, regenerative & electromagnetic w/ manual release
• Weight Capacity: 350 lbs. Without Power Seat Lift Option
• Weight Capacity: 250 lbs. WITH Power Seat Lift Option
• Seat type - Premier I (standard):
  • Foldable molded plastic
  • Material: Black Vinyl (snap on 2-1/4” thick seat)
  • Width adjustable flip-up arms
  • 360° Swivel w/Seat Lock
  • Standard Seat Weight: 25 lbs.
  • Standard Seat Width: 18"
  • Standard Seat Depth: 17" usable
  • Seat Back Height: 16"
• EZ-Tilt handle with HI/LO speed controls
• Body colors:

Note: Turning radius derived in accordance with ANSI/RESNA methodology

Includes batteries and charger.

Amigo Limited Lifetime Warranty
