Maxima 4 Wheel Heavy Duty Mobility Scooter

The Maxima 4-Wheel Scooter combines outstanding performance and elegant styling together with rugged construction for an increased weight capacity of up to 500 pounds for the larger rider! With a list of standard features like an easily adjustable tiller, fully directional light package, 22" wide medium-back seat, 7-piece disassembly, ultra heavy-duty drive train, enhanced rear suspension, rear view mirror, front tiller basket, flat-free tires -- the Maxima provides heavy-duty brawn with all the convenience and comfort of a luxury scooter.Features:

• 500 lbs. Weight capacity.
• Accommodates up to NF-22 batteries (included) for maximum range.
• Fully directional light package.
• Ultra heavy-duty drivetrain with 110-amp controller.
• 26" width for optimal stability.
• Flat-free rubber tires.
• Maximum speed up to 5.25 mph.
• Easy-to-use external freewheel lever.
• 7-piece disassembly without tools.
• Front basket.
• Handle bar mounted rear view mirror.
• On-board battery charger.
• On-board rear accessory bracket.
• Convenient tie-down points.
• Manufacturer's Suggested Retail for this package = $4050.00

Specifications:

• Overall Length: 47.5"
• Overall Width: 26"
• Weight w/o Batteries: 189 lbs.
• Weight w/ 55 AH batteries: 266 lbs.
• Heaviest piece disassembled (rear section): 72.5 lbs.
• Battery: (2) UPGRADED 55 AH NF-22 12VDC Gel Deep Cycle
• Battery Charger: Off-board, 5-amp
• Per-charge Range (Max): up to 30 Miles. (varies w/ passenger weight, terrain type, battery charge and condition)
• Maximum Speed: up to 5.25 mph (may vary with terrain)
• Turning Radius: 58"
• Wheels: Attractive Micro Mags
• Tires: Front - 3" X 10" Solid, Rear - 4" X 10" Solid
• Ground Clearance: 4.5"
• Drive Train: Rear-wheel drive, 24V sealed transaxle
• Dual Braking System: Electronic, regenerative and electromechanical
• Seat type (standard):
  • Contoured medium-back seat
  • Material: Beige, Black, Brown or Gray VINYL Brown or Gray FABRIC
  • Width & Height adjustable flip-up arms
  • Standard Seat Weight: 45 lbs.
  • Standard Seat Width: 22"
  • Standard Seat Depth: 18" usable
  • Back Seat Height: 22"
• Maximum Weight Capacity: 500 lbs.
• Body colors: Candy Apple Red, Viper Blue
• Disassembly: 7 pieces Note: Turning radius derived in accordance with ANSI/RESNA methodology Warranty Information:
  • Three-year Limited Warranty on Structural Frame Components (including platform, fork, seat post, and main/tiller frames).
  • Three-year Pro-rated Warranty on Drive train (including transaxle, motor, and brake).
    • First year: 100% replacement of parts cost.
    • Second year: 67% replacement of parts cost (other than 3 year warranted parts).
    • Third year: 50% replacement of parts cost (other than 3 year warranted parts).
  • One-Year Limited Warranty For one year from the date of purchase, Pride Mobility Products Corporation will repair or replace, at their option, to the original purchaser, free of charge, any of the following parts found upon examination by an authorized representative of Pride Mobility Products Corporation to be defective in material and/or workmanship.
    • Bearings
    • Bushings
    • Rubber Components
    • Plastic Components (except body)
    • Electronic Controllers
    • Chargers
    • Wiring Harnesses
    • Any other electrical subassembly
  • Warranty Exclusions for any items which may require replacement due to normal wear and tear.
    • ABS Plastic Shrouds (Body Parts)
    • Motor brushes
    • Brake Pads
    • Tires and Tubes
    • Upholstery and seating
    • Fuses/Bulbs
    • Circumstances beyond the control of Pride
    • Labor, service calls, shipping, and other charges incurred for repair of the product, unless specifically authorized, IN ADVANCE, by Pride Mobility Products Corporation.
    • Repairs and/or modifications made to any part without specific consent from Pride
    • Damage caused by contamination
    • Damage caused by abuse, misuse, accident, or negligence
    • Commercial use, or other use other than normal
    • Improper operation, maintenance, or storage
  • Batteries: The Batteries are not warranted by Pride Mobility Products Corporation. Batteries usually have a Six (6) Month warranty by the battery manufacturer.
• Service Checks and Warranty Service must be performed by a dealer or provider authorized by Pride or by Pride Mobility Products Corporation. All transportation costs and shipping damaged incurred while submitting parts for repair or replacement are the responsibility of the original purchaser. In some cases there may be a labor charge to remove and replace warranted parts.
