Quickie Ti Titanium

• Custom tailored frame options
• Easy-to-load design
• Patent-pending caster pivot-adjuster
• Titanium is 3 times stronger than aluminum
• Please call to order 1-800-861-3211

Product Overview

The Quickie Ti Titanium is the latest addition to our family of ultra-lightweight rigid chairs. Using lightweight titanium tubing, a minimalist design, and several patented features, our engineers have succeeded in developing the perfect balance between form and function. With a chair weight averaging between 15 and 17 lbs., the Quickie Ti Titanium is the best choice for today's active user.

Product Highlights

The Titanium Advantage Titanium alloy is approximately 3 times stronger than aluminum. This advantage in strength makes it possible to build a lighter, simpler frame. Titanium tubing also provides a more controlled rebound and superior torque strength. With an average weight of 16.9 lbs, the Quickie Ti Titanium is Allegro Medical's premium rigid-chair choice. Patent-Pending Caster Pivot-Adjuster To reduce excess weight and flutter, our engineers have eliminated the caster housing so that the caster fork now threads directly into the frame. A special pivot caster-adjuster allows the forks to pivot 16° in 2° increments. This feature enables the user to adjust the seat "slope" between 1" - 3.5" while maintaining a perpendicular caster-wheel/ground alignment. Custom Tailored Frame Options To ensure the best possible fit, our engineers have developed over 4,000 different frame configurations. Each frame can be customized in six different ways: frame angle (70°, 80°, 85°), frame inset (1", 2", 3"), front seat-height (16"- 20" in 1/2" increments), rear seat-height (14"-19" in 1/2" increments), seat width (13"-18"), and seat depth (14"-19). Easy-To-Load Design A fold-down back, "L" shaped frame and extremely low frame-weight make vehicle transfers about as easy as loading a briefcase.

The new Quickie Ti Titanium chair is distinctly different from the Quickie (GPV) Ti Titanium. Its new mono-tube construction and reduced weight create a fresh concept in titanium chair design. The Quickie (GPV) Ti Titanium chair is now referred to as the "Quickie GPV Titanium". The rear axle features 4" of center-of-gravity adjustment in 1/2" increments. When a chair is not properly centered, it feels heavy, unresponsive, and sometimes "tippy". By using a 4" adjustment range that accommodates many different body types, this problem can be avoided. The Quickie Ti Titanium features new fold-down push handles. Push handles sometimes act like fish hooks when pulling a chair out of storage. In contrast, fold-down push handles allow the chair to slide out without hooking everything else. A special flat area on the axle-sleeve nut corrects toe-in and toe-out in three easy steps: Loosen the camber tube. Place a square against the flat area on the axle-sleeve nut and the ground. Re-tighten the camber tube. The wheels are now aligned. The axle plate features 3" vertical adjustment in 1/2" increments. This provides plenty of space to adjust wheel sizes, seat height and seat angle. The rear camber tube is secured to the axle plate with a special compression axle sleeve. The axle sleeve is held together with Torx head screws. This advanced hardware is superior in design and holding power. A special tool kit containing Torx wrenches ships with the chair.

Technical Specifications Built to meet the requirements of HCPCS code: Pending Product Weight: Approx. 15 - 20 lbs. Product Width: 13 in. - 18 in. seat width Product Length/Depth: 14 in. - 19 in. seat depth Product Height: 16 in. - 20 in. seat to floor Shipping Dimensions (box 1): 31"w X 24"h X 24"d Ship Method(s): Ground, Next Day, 2 Day, 3 Day Product Weight Capacity: 250 lbs. Overall Width 19 in. - 31 in. Caster Options 3 in., 4 in., 5 in. Rear Wheel Options 24 in., 24 in. heat treated, 26 in., 26 in. heat treated Axle Options Standard stainless-steel, optional Titanium, and quad-release axle nuts

Total Chair Weight Calculation Sheet
