- Adjusts from 3' up to 5' long
- 7" wide treads
- 6 lbs. per ramp
- Can be used on steps, vans, or curbs
- Designed for manual or power wheelchairs
- Telescope for compact storage
- Great for home or travel
- Quantity: 1 pair
5' Telescoping Adjustable Wheelchair Ramps
Allegro Medical presents the 5' Telescoping Adjustable Wheelchair Ramps. These retractable, adjustable wheelchair ramps are a handy item to have in your home so wheelchair users can easily come and go from rooms that have steps. They are also great to have around for visitors if your entrance has a step or curb. Wheelchair users will also find them invaluable when visiting friends or family who may not have accessible entrances. Light and compact, these portable ramps are easy to travel with or store in the truck of your car. Each ramp weighs only 6 pounds, making them easy to lift and position. They extend from 3 to 5 feet, so you can use them on different step sizes and heights (see measuring directions). Each ramp can support 330 pounds (660 pounds total between them).
How to Use
Two ramps are included. To extend the ramps, pull sections one and two until the locking buttons are fully extended into the holes and snap into place. After use, simply retract them and put them away in their convenient nylon carrying bag. They are easy to take with you when traveling.
How to Measure for Wheelchair Ramps
To calculate the length of the ramp you will need, first you need to measure the rise. The rise is the measurement between the ground and where the top of the ramp will be placed. The American with Disabilities Act (ADA) requires that public areas have wheelchair ramps with an incline of 4.8 degrees or less (a ratio of 1:12). This equals one foot of ramp for every inch of rise. For residential areas such as homes, ADA recommends a 2:12 slope. This equals one foot of ramp for every two inches of rise. To calculate the ramp length you will need, divide the rise by two. For home use, these ramps would work for rises up to 10 inches.
Next, you need to measure the width of your wheelchair’s wheels. These ramps have an inner track area of 4 inches. Be certain each wheel is no wider than 4 inches before ordering.
Features
- Two telescoping, adjustable wheelchair ramps easily extend for use with steps, curbs or vehicles then retract for storage.
- Strong rust resistant aluminum construction with durable non-skid u-shaped tracks for added safety
- Easily adjustable from 3 to 5 feet with push-button lock mechanism; see measuring instructions before ordering
- Each ramp can support up to 330 pounds for a total of 660 pounds between them.
- Ramps are lightweight (6 pounds each) and portable in a convenient nylon storage bag; great for travel.
- Inside track area: 4 inches wide
- Retracted size: 6.5 x 29 inches
- Easy to assemble with no tools
| Brand Name | Mabis DMI |
| Manufacturer Number | 517-4094-0000 |
Questions:
The ramps appear to be 7.5'' wide from edge to edge. What is the width of the inside of the ramp between the two outer track rails? Need to make sure that both the casters and tires/hand rims will fit on.
0 Answers
Questions:
Can the ramps be put in at two different lengths to accommodate a circular step?
0 Answers
Questions:
WHAT IS THE WEIGHT CAPACITY ON THESE RAMPS?
0 Answers
Questions:
how long of a ramp is needed for 5 stairs at 7 1/4 high?
0 Answers
Questions:
Can you purchase two (2) sets of ramps and somehow connect them to create a longer ramp with additional uses?
0 Answers
Questions:
Is it easier to pull vs. push a wheelchair up a ramp, so that a shorter ramp would work? Would a one-piece ramp be easier for a helper than two separate tracks? Thank you!
0 Answers
Questions:
Will these work, for 5 stairs, for a manual occupied wheelchair or do I need something longer?
0 Answers
Questions:
is this ramp recommended for motorized wheel chair use?
0 Answers
Questions:
Can these ramps be used to load a power wheelchair into the back of a Ford Edge crossover SUV?
1 Answers
Questions:
I'm a caregiver, currently lifting a basic wheelchair into the back of my mini van. Could this 5' length work?
1 Answers
Questions:
how wide are the ramps?
1 Answers
Questions:
how wide are the ramps ?
1 Answers
Questions:
My two stairs have a total rise of 15". Is the 5 foot ramp long enough to allow a wheelchair to go up or down without tipping?
1 Answers
Questions:
Would this work for Jazzy Power Chair to put in Van??
1 Answers
Questions:
I need a cheap ramp for my powerchair to fit in a 1998 Honda CRV Trunk.and fit a Ford f-150 truck bed. What can I get?
1 Answers
Questions:
How wide are the tracks? I don't see that dimension mentioned. Please.
Thanks,
Candy
1 Answers
Questions:
do you get the left and right ramps for the $99
1 Answers
Questions:
Please explain how to calculate the length of the ramp needed for the height of the stair(s)?
1 Answers
Questions:
My two stairs have a total rise of 15". Is the 5 foot ramp long enough to allow a wheelchair to go up or down without tipping?
1 Answers
